HOW TO MEASURE WASHER & DRYER DIMENSIONS GUIDE
MEASURING FOR WASHER AND DRYER DIMENSIONS
When measuring a space for the right width, depth or height of washer and dryer, make sure to consider utility requirements, clearance space and even accessibility for loading and unloading.
From standard washer and dryer sizes to stackable washer and dryer dimensions, this guide will help you find the best fit for the job. If you already have a laundry pair picked out, you can locate the exact dimensions online or ask your local sales representative for assistance.
THE ULTIMATE LAUNDRY PAIR MEASURING GUIDE
WHAT YOU’LL NEED
Measuring Tape
This Guide
4 STEPS FOR MEASURING YOUR LAUNDRY SPACE
Measurements shown below are examples on Maytag® front-load washer and dryer models MHW8630H & YMED8630H
Washer
Height: 38 ⅝” (98.2 cm)
Width: 27” (68.6 cm)
Depth: 32 15/16” (83.7 cm)
Dryer
Height: 38 ¾” (98.4 cm)
Width: 27” (68.6 cm)
Depth: 30 ¾” (78 cm)
STEP 1: SETTLE ON A SETUP
On pedestals
*for front-load-only
Side-by-side
*for front-load-only
Stacked
STEP 2: CONSIDER THE DISTANCE
In front of the pair
Add roughly 4’ (122 cm) for easy loading/unloading. In a closet, ensure the unit doors clear the closet doorway.
Behind the pair
Add approximately 6” (15.2 cm) for hoses and venting space.
To minimize noise
Add approximately 1” (2.5 cm) of space on each side of the units: top, sides and between the pair.
Above the washer
Add extra space for easy opening/closing. Note: for top-load only
STEP 3: MEASURE HEIGHT, WIDTH AND DEPTH
Measurements shown below are examples on Maytag® front-load washer and dryer models MHW8630H & YMED8630H
Stacked
*for front-load only
Height: 77½” (196.9 cm)
Width: 29” (73.7 cm)
Depth: 38 15/16” (98.9 cm)
Side-by-side
Height: 39¾” (100.9 cm)
Width: 57” (144.8 cm)
Depth: 38 15/16” (98.9 cm)
On pedestals
*for front-load-only
Height: 54 ¼” (137.8 cm)
Width: 57” 144.8 cm)
Depth: 38 15/16” (98.9 cm)
STEP 4: MAP OUT A PATH
Figure out the best path of entry: from your home entrance, through each hall and any doorway, Then measure the width of those spaces to ensure the unit will make it through.
FINDING YOUR WASHER & DRYER SIZES
To determine the exact dimensions of the washer and dryer models you’re interested in, look up the model number online to review specs or ask your local sales representative for assistance. The washer and dryer size guide above represents a Maytag® front-load laundry pair.
